Aluminium Railing Profiles manufactured by Satya Metal Industries Pvt. Ltd.

Aluminium Railing Profiles

Base channels, handrails and cap sections for glass and panel railings on balconies, staircases and terraces, made in Rudrapur with in-house anodizing and powder coating for outdoor use.


13+ Years of Excellence
30,000 MT+ Annual Capacity
7 Extrusion Presses
3,50,000+ Sq. Ft. Manufacturing Area

Last updated:

Satya Metal Industries Pvt. Ltd.

Aluminium Railing Profiles Manufacturer in India

Aluminium railing profiles are the extruded base channels, handrails, caps and connecting sections that hold glass or panel infill on balconies, staircases and terraces. Satya Metal Industries Pvt. Ltd. makes them in Rudrapur, Uttarakhand, from its own billets and dies, with sections ranging from light handrail profiles to heavy base channels that clamp toughened glass. Railing fabricators, glass installers, builders and dealers buy them mill finish or with outdoor-grade anodizing and powder coating.

Quick Answer

Satya Metal Industries Pvt. Ltd. is an aluminium railing profiles manufacturer in India making base channels, handrails and cap sections in Rudrapur, Uttarakhand. Its 2-page catalogue lists each section with a profile code and weight per metre, from 0.616 kg/m up to 5.268 kg/m for the 120 mm wide base section, and carries BIS marks for IS 733 and IS 1285.

Aluminium railing profiles for glass railings by Satya Metal Industries Pvt. Ltd.
Product Catalogue

Aluminium Railing Profiles Catalogue

Our aluminium railing profiles catalogue shows each section with a dimensioned drawing, profile code and weight per metre. Weight per metre is a useful first check of how much load a base section can carry.

2Catalogue Pages
Up to 5.268kg/m Base Section
IS 733 / 1285BIS Marks
30,000 MT+Yearly Capacity
Aluminium Railing Profiles Catalogue (PDF)2 pages with section drawings, profile codes and weights

Sample Sections From the Catalogue

Every section in the catalogue has a profile code, a dimensioned drawing and its weight per metre. A few examples:

Profile CodeMain Dimensions (mm)Weight (kg/m)
366204120 x 45.35.268
36620560 x 451.513
36620640 x 350.616

Dimensions are read from the catalogue drawings. Open the full catalogue for every section, and quote the profile code when you order.

Specifications

Aluminium Railing Profiles Specifications

SpecificationDetails
ProductAluminium Railing Profiles
ManufacturerSatya Metal Industries Pvt. Ltd., Rudrapur, Uttarakhand
Alloy6063 (other grades on request)
Profile TypesGlass railing base channels, handrails, caps and connecting sections
FinishesMill finish, anodizing (matte or gloss), powder coating in RAL shades, wood grain
FabricationCut to length, punching, drilling and machining on request
Catalogue2 pages, profile code and kg/m for every section
BIS Marks in CatalogueIS 733 (CM/L-8300192310) and IS 1285 (CM/L-8300192411)
Management CertificationsISO 9001:2015, ISO 14001:2015
Custom SectionsMade to your drawing with dies from our own tool room
SupplyPan-India and export, from 30,000 MT+ yearly capacity
Applications

Where Aluminium Railing Profiles Are Used

Aluminium railings are light, do not rust, and need far less upkeep than mild steel or wood, which is why they are now common on apartments and commercial buildings.

Balcony Glass Railings

Base channels that clamp toughened glass for a clear, frameless look.

Staircase Railings

Handrails and base sections for internal and external stairs.

Terraces and Rooftops

Outdoor railings with anodized or powder coated finishes.

Pool Decks

Railings near water, where aluminium avoids the rust problems of steel.

Commercial Atriums and Malls

Railings for mezzanines, atriums and walkways.

Handrails and Caps

Top rails that protect the glass edge and give a comfortable grip.

Buyer's Guide

How to Choose the Right Aluminium Railing Profiles

Railings are a safety item, so check these points with your structural consultant before you finalise sections.

Your RequirementWhat to CheckHow Satya Metal Handles It
Correct glass thicknessInner width of the base channel against glass plus gasketCatalogue drawings show channel dimensions, and our team confirms fit for your glass
Higher wind or crowd loadsA heavier, deeper base section and the fixing designHeavy base sections up to 5.268 kg/m. Final design should be approved by your structural engineer
Outdoor or coastal sitesProtective finish on all exposed facesAnodizing or powder coating done in-house and checked in our wet chemical lab
Handrail matching the baseSame finish from the same batchBase, cap and handrail finished together from our own billets
Faster installation on sitePre-cut lengths and fixing holesCutting, punching and drilling on our automatic fabrication lines
Surface Finishes

Finish Options for Aluminium Railing Profiles

All finishing is done in-house at our Rudrapur units, so colour and coating quality are controlled by the same team that extrudes the section.

Mill Finish

Bare aluminium for profiles that will be clad or coated by the fabricator.

Anodizing (Matte or Gloss)

A hard oxide layer in matte or gloss, suited to outdoor railings that need low upkeep.

Powder Coating (RAL Shades)

Any RAL shade, often black, grey or white to match the facade.

Wood Grain Finish

A wood look for handrails without the maintenance of real timber.

Manufacturing

How We Make Aluminium Railing Profiles

Base channels must hold glass tightly along their full length, so straightness and wall thickness matter more here than in most profiles.

1

Own Billets

Logs cast on our hot top casting line, with a spectrometer check on every melt.

2

Own Dies

Dies made in our tool room on VMC, wire-cut EDM and EDM machines.

3

Extrusion and Ageing

Extruded on 7 presses (600 MT to 2,750 MT), stretched, corrected and aged.

4

Finish and Fabricate

Anodized, powder coated or wood grain finished, then cut and machined if needed.

Full plant details are on our page about the top aluminium extrusion manufacturer in India.

Who Buys

Who Buys Our Aluminium Railing Profiles

Railing Fabricators

Base, handrail and cap sections from one supplier in one finish.

Glass Installers

Base channels sized for common toughened glass thicknesses.

Builders and Developers

Project volumes for apartment balconies and staircases.

Dealers and Distributors

Standard catalogue sections for stocking and resale.

Frequently Asked Questions About Aluminium Railing Profiles

Aluminium railing profiles are extruded base channels, handrails, caps and connecting sections that hold glass or panels in balcony, staircase and terrace railings.

Satya Metal Industries Pvt. Ltd. manufactures aluminium railing profiles in Rudrapur, Uttarakhand, with its own billets, dies and in-house finishing, and supplies across India.

It depends on the channel. Check the inner width in our catalogue drawings and share your glass thickness, and our team will confirm the right section and gasket.

Our catalogue sections range from 0.616 kg/m to 5.268 kg/m. The heaviest, code 366204, is 120 mm wide and 45.3 mm deep.

Yes. Aluminium does not rust, and an anodized or powder coated finish adds protection for terraces, pool decks and coastal buildings.

Railing profiles are usually extruded in 6063 alloy for a good finish. We can advise another grade if your design needs higher strength.

Our railing profiles catalogue carries BIS marks for IS 733 and IS 1285, along with ISO 9001:2015 and ISO 14001:2015 certification.

Yes. We supply railing profiles cut to length, punched and drilled on our fabrication lines, ready for site installation.

Get a Quote

Order Aluminium Railing Profiles From Satya Metal

Send the profile codes from our catalogue (or your drawing), glass thickness, finish, lengths and quantity. We will reply with price and dispatch time.
